1-66359-7
Iii+ Pin, 18-14, Tin-Lead, Strip, 1-66359-7
Availability: Out of Stock
What is SnapEDA?
SnapEDA is a free library of symbols & footprints for the 1-66359-7 by TE Connectivity / AMP and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 24 hours!
More
Relevant part with 2D models
| Verification | Issues | Specs |
Specifications for the 1-66359-7
| Part Name | 1-66359-7 |
| Manufacturer | TE Connectivity / AMP |
| Contact Base Material | Cu-Ni Alloy |
| Contact Size | 16 |
| Accepts Wire Insulation Diameter Range | 2.03 – 2.54 |
| Wire Insulation Support | With |
| Product Type | Contact |
| Packaging Method | Reel |
| Wire/Cable Type | Discrete Wire |
| Operating Temperature Range | -55 – 90 |
| Contact Underplating Material | Nickel |
| Contact Mating Area Plating Thickness | 100 |
| Contact Mating Area Plating Material | Precious Metal |
| Underplate Material Thickness | 50 |
| 端子の下地めっきの材料 | Nickel |
| Contact Current Rating (Max) (A) | 25 |
| Test Current (A) | 25 |
| Termination Type | Crimp |
| TE Internal Number | 1-66359-7 |
| Circuit Application | Power & Signal |
| For Use With | VDE Connectors |
| Mating Pin Diameter | .062 |
| Contact Termination Area Plating Thickness | 100 |
| Packaging Quantity | 4000 |
| Wire Size | .8 – 2 |
| Contact Termination Area Plating Material | Tin-Lead |
| Connector & Contact Terminates To | Wire & Cable |
| Contact Type | Pin |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
