171633-1
E-J MK-2 250 TAB CONT
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 171633-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 171633-1
| Part Name | 171633-1 |
| Manufacturer | TE Connectivity |
| Wire Size | 1.25 – 3.37 |
| Operating Temperature Range | -30 – 105 |
| Terminal & Splice Type | Tab |
| Packaging Method | Reel |
| Wire Insulation Diameter | .161 – .216 |
| TE Internal Number | 171633-1 |
| Wire Size Search | 2.5 |
| Crimp Type | F-Crimp |
| Interface Plating | None |
| Mating Tab Thickness | .8 |
| Termination Method | Crimp |
| Packaging Quantity | 3000 |
| Sealable | Yes |
| RoHS | True |
| Mating Tab Width | .248 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 171633-1 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
9,000 x $0.10
|
Visit Site | |
|
★ Featured
|
3,000
|
9,465 x $0.03
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Buerklin |
|
|
Visit Site | |
| Farnell UK |
5,400
|
|
Visit Site | |
| Heilind Americas |
|
|
Visit Site | |
| Interstate Connecting Components |
|
|
Visit Site | |
| Mouser |
|
|
Visit Site | |
| Newark |
5,400
|
|
Visit Site | |
| Verical |
6,000
|
|
Visit Site | |
| element14 Singapore |
5,400
|
|
Visit Site |
No issues have been reported for the 171633-1
If you experienced any issues with this part, please report it.
