2-1478763-5
ADK Series Series Die Cast Zinc Angled D-sub Conn Backshell 25 Way Strain Relief | TE Connectivity 2-1478763-5
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2-1478763-5 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2-1478763-5
| Part Name | 2-1478763-5 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Cable Insulation Diameter | .197 – .355 |
| Shield Plating Material | Nickel |
| Grommets | With |
| Shielded | Yes |
| Packaging Method | Bag |
| Screw & Hole Thread Size | 4-40 |
| Accessory Type | Backshell |
| TE Internal Number | 2-1478763-5 |
| Packaging Quantity | 100 |
| Grommets per Set | 4 |
| Cable Exit Angle | 45 |
| Slide Latch | Without |
| Shell Size | 3 |
| Cable Clamp Type | Two-Piece RFI/EMI Shield |
| Number of Positions | 25 |
| Cover Flammability Rating | UL 94V-2 |
| Backshell Material | Zinc |
| RoHS | True |
| Cable Clamp Material | Die Cast |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 2-1478763-5 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
|
Visit Site | |
|
★ Featured
|
45
|
|
Visit Site | |
|
★ Featured
|
2,210
|
107 x $3.27
|
Visit Site | |
| Arrow Europe |
905
|
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Buerklin |
|
|
Visit Site | |
| Farnell UK |
2,212
|
|
Visit Site | |
| Heilind Americas |
82
|
|
Visit Site | |
| Newark |
2,212
|
|
Visit Site | |
| Onlinecomponents |
405
|
|
Visit Site | |
| Sager |
|
|
Visit Site | |
| TTI Americas |
|
|
Visit Site | |
| Verical |
904
|
|
Visit Site | |
| element14 Singapore |
2,212
|
|
Visit Site |
No issues have been reported for the 2-1478763-5
If you experienced any issues with this part, please report it.
