66565-1
MULTIMATE Type III+ Series 24-20 AWG Discrete Wire Crimp Signal Socket Assembly
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 66565-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 66565-1
| Part Name | 66565-1 |
| Manufacturer | TE Connectivity / AMP |
| Underplate Material Thickness | .76 |
| Circuit Application | Power & Signal |
| Contact Mating Area Plating Material | Gold |
| Contact Termination Area Plating Thickness | 10 |
| For Use With | Special M Series |
| Connector & Contact Terminates To | Wire & Cable |
| Test Current (A) | 13 |
| Color Code | Yellow |
| TE Internal Number | 66565-1 |
| Contact Underplating Material | Nickel |
| Product Type | Contact |
| Wire Insulation Support | With |
| Contact Size | 16 |
| Operating Temperature Range | -55 – 150 |
| Packaging Method | Carton |
| Packaging Quantity | 1000 |
| Contact Base Material | Brass |
| Contact Termination Area Plating Material | Gold |
| Accepts Wire Insulation Diameter Range | .06 – .12 |
| Barrel Type | Open Barrel |
| RoHS | True |
| 端子の下地めっきの材料 | Nickel |
| Contact Current Rating (Max) (A) | 13 |
| Contact Mating Area Plating Thickness | 30 |
| Termination Type | Crimp |
| Mating Pin Diameter | .062 |
| Contact Type | Socket |
| Wire/Cable Type | Discrete Wire |
| Wire Size | 24 – 20 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the 66565-1
