1-102156-0
Conn Ejector Header HDR 50 POS 2.54mm Solder ST Thru-Hole Tray
Availability: Out of Stock
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-102156-0 by TE Connectivity AMP Connectors and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-102156-0
| Part Name | 1-102156-0 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Center |
| Centerline (Pitch) | 2.54 |
| Temperature Rating | Standard |
| Circuit Application | Signal |
| Insulation Resistance | 5000 |
| Housing Style | 4-Sided |
| Housing Material | Thermoplastic |
| Row-to-Row Spacing | 2.54 |
| Contact Termination Area Plating Thickness | 100 |
| Operating Voltage (V) | 250 |
| Ejection Latches | Without |
| Connector Style | Receptacle |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Screw Mount |
| Profile | Standard |
| PCB Mount Retention | Without |
| PCB Thickness (Recommended) | 3.18 |
| Board Standoff | Without |
| TE Internal Number | 1-102156-0 |
| Polarization | With |
| PCB Mount Orientation | Vertical |
| Connector System | Board-to-Board |
| Number of Rows | 2 |
| Housing Color | Black |
| Header Type | Universal Ejection Pin Headers |
| Contact Underplating Material | Nickel |
| Product Type | Connector |
| Connector Mounting Type | Board Mount |
| Contact Shape | Square |
| Contact Design | Solder Dip |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Operating Temperature Range | -65 to 105 |
| Packaging Method | Tray |
| Connector Type | Header |
| Packaging Quantity | 30 |
| Contact Termination Area Plating Material | Gold Flash over Palladium Nickel |
| Number of Positions | 50 |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold Flash over Palladium Nickel |
| Shrouded End Dimension | 3.81 |
| Contact Transmits (Typical) | Signal (Data) |
| Mating Retention | Without |
| Contact Base Material | Brass |
| Termination Post Length | 3.94 |
| PCB Mount Alignment | With |
| Post Size | .025 |
| UL Flammability Rating | UL 94V-0 |
| Height | .55 |
| Panel Mount Feature | Without |
| Contact Current Rating (Max) (A) | 1 |
| Contact Mating Area Plating Thickness | 30 |
| Contact Type | Pin |
| PCB Contact Termination Area Plating Material | Tin-Lead |
| Mating Connector Lock | Without |
| Daisy Chain | Without |
