1-1478033-0
Straight 75Ohms Through Hole BNC Connector, jack, Solder Termination Nickel | TE Connectivity 1-1478033-0
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-1478033-0 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-1478033-0
| Part Name | 1-1478033-0 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| RF Contact Captivation Method | Mechanical |
| Port Configuration | Single Port |
| TE Internal Number | 1-1478033-0 |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Body Insulation | With |
| Panel Thickness (Recommended) | 1.5 – 5.5 |
| RF Connector Style | Jack |
| RF Connector Coupling Mechanism | Bayonet |
| RF Connector Center Contact Material | Brass |
| Dielectric Material | Polyethylene |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention | With |
| PCB Thickness (Recommended) | 3.2 |
| Flange and Thread Material | PBT Polyester |
| PCB Tail Length | 4.3 |
| PCB Mount Orientation | Vertical |
| Connector System | Cable-to-Board |
| Body Plating Material | Nickel |
| Number of Coaxial Contacts | 1 |
| Housing Color | White |
| Impedance | 75 |
| Sealable | No |
| Connector Mounting Type | Board Mount |
| RF Connector Mated Outer Diameter (Approximate) | .572 |
| Panel Attachment Style | Rear Mount |
| Panel Cutout | 12 x 12.9mm D-Shape |
| Operating Temperature Range | -67 – 185 |
| Flange and Thread Material Color | White |
| Packaging Method | Box |
| RF Interface | BNC |
| Detent | With |
| Body Material | Zinc |
| Number of Positions | 1 |
| Mounting Post Length | .169 |
| Operating Frequency | 2 |
| Panel Mount Feature Type | Hex Nut |
| RoHS | True |
| Life Cycle Status | Obsolete |
| RF Connector Center Contact Plating Material | Gold |
| Cable Type | RG Coax Cable |
| Grade | Commercial |
| Height Above PC Board | 1.374 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Series | ZDC |
| Body Plating | Nickel |
| Mounting Type | PCB Mount |
| Gender | Female |
| Body Orientation | Straight |
| Bulkhead | Yes |
| Coaxial Connector Type | BNC Connector |
| Minimum Operating Temperature | -55 (°C) |
| Termination Method | Through Hole |
| Operating Frequency | 0 to 2 (GHz) |
| Impedance | 75 (Ω) |
| Contact Plating | Gold |
| Maximum Operating Temperature | +85 (°C) |
| Contact Material | Brass |
Inventory for the 1-1478033-0 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
1,000 x $1.68
|
Visit Site | |
|
★ Featured
|
1,054
|
|
Visit Site | |
| Mouser |
|
N/A | Visit Site |
No issues have been reported for the 1-1478033-0
