1-1571994-0
510 SIP MACHINED, 510-AG91D-10LF SIP SOCKET ASSY | TE Connectivity 1-1571994-0
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-1571994-0 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-1571994-0
| Part Name | 1-1571994-0 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Centerline (Pitch) | 2.54 |
| Circuit Application | Signal |
| Sleeve Plating Material | Tin |
| Housing Material | Thermoplastic |
| Contact Fabrication | Screw Machine |
| Connector & Contact Terminates To | Printed Circuit Board |
| TE Internal Number | 1-1571994-0 |
| Number of Positions | 10 |
| Number of Rows | 1 |
| Leg Style | Standard |
| Contact Base Material | Beryllium Copper |
| Connector Mounting Type | Board Mount |
| Operating Temperature Range | -67 – 257 |
| Sleeve Material | Copper |
| Packaging Quantity | 48 |
| Height Above PC Board | 4.57 |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Life Cycle Status | Obsolete |
| Product Type | Socket |
| Breakaway Header | Yes |
| Termination Post Length | 3.18 |
| Color | Black |
| Socket Type | SIP |
| UL Flammability Rating | UL 94V-0 |
| Contact Current Rating (Max) (A) | 3 |
| Contact Mating Area Plating Thickness | 20 |
