1-1624094-8
WireWound SMD Inductor w/ FerriteCore,4.7 uH +/-10%WireWound 315mA Idc | TE Connectivity 1-1624094-8
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-1624094-8 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-1624094-8
| Part Name | 1-1624094-8 |
| Manufacturer | TE Connectivity |
| Category | Electronic Components |
| Mount Style | Surface Mount |
| Current Rating (Max) (A) | 315 |
| Operating Temperature Range | -30 – 100 |
| Shielded | No |
| Packaging Method | Taped & Reeled |
| Quality Factor | 50 |
| Package | 1812 |
| Element Type | Wirewound |
| TE Internal Number | 1-1624094-8 |
| Self Resonant Frequency | 35 |
| Dimensions | 4.5 x 3.2 x 3.2 |
| Size Code | 1812 |
| Inductance | 4.7 |
| DC Resistance | 1 |
| Tolerance | 10% |
| RoHS | True |
| Lead Type | Surface Mount Terminals |
