1-1658694-2
Conn Ejector Header HDR 60 POS 2.54mm Press Fit ST Thru-Hole Tray
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-1658694-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-1658694-2
| Part Name | 1-1658694-2 |
| Manufacturer | TE Connectivity |
| Wire-to-Board | |
| Mating Alignment Type | Center |
| Centerline (Pitch) | 2.54 |
| Temperature Rating | High |
| Circuit Application | Signal |
| Insulation Resistance | 5000 |
| Housing Style | 4-Sided |
| Polarization | With |
| Row-to-Row Spacing | 2.54 |
| Contact Termination Area Plating Thickness | 100 |
| Connector Style | Plug |
| Ejection Latches | Without |
| Height | .55 |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Action/Compliant Tail |
| Profile | Standard |
| PCB Mount Retention | With |
| Post Numbers Omitted | None |
| PCB Thickness (Recommended) | .08 |
| Housing Material | Nylon or Polyester |
| Board Standoff | Without |
| TE Internal Number | 1-1658694-2 |
| PCB Mount Orientation | Vertical |
| Connector System | Wire-to-Board |
| Solder Tail Contact Plating Thickness | Tin: 100- Nickel: 50 |
| Number of Rows | 2 |
| Housing Color | Black |
| Header Type | Universal Ejection Pin Headers |
| Contact Underplating Material | Nickel |
| Product Type | Connector |
| Connector Mounting Type | Board Mount |
| Contact Shape | Square |
| Contact Transmits (Typical) | Signal (Data) |
| Termination Method to Printed Circuit Board | Through Hole - Press-Fit |
| Operating Temperature Range | -65 to 105 |
| Contact Retention in Housing | Press-Fit |
| Packaging Method | Tray |
| Connector Type | Header |
| Packaging Quantity | 30 |
| Shrouded End Dimension | 3.81 |
| Contact Termination Area Plating Material | Tin |
| Number of Positions | 60 |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold Flash over Palladium Nickel |
| Panel Mount Feature Type | Mounting Ears |
| RoHS | True |
| Mating Retention | With |
| Contact Base Material | Brass |
| Termination Post Length | 4.42 |
| PCB Mount Alignment | Without |
| Post Size | .025 |
| Length | 3.76 |
| Housing Entry Style | Top |
| Panel Mount Feature | Without |
| Contact Current Rating (Max) (A) | 1 |
| Contact Mating Area Plating Thickness | 30 |
| UL Flammability Rating | UL 94V-0 |
| Contact Type | Pin |
| PCB Contact Termination Area Plating Material | Tin |
| ??? | AMP-Latch Receptacle |
| Mating Connector Lock | Without |
| Daisy Chain | Without |
