1-1705949-1
Cat3 4P4C Right Angle Through Hole RJ22 Modular Jack Connector | TE Connectivity 1-1705949-1
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-1705949-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-1705949-1
| Part Name | 1-1705949-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Centerline (Pitch) | 1.02 |
| Circuit Application | Signal |
| Port Configuration | Single Port |
| Modular Jack Latch Orientation | Standard - Latch Down |
| Housing Material | PBT GF |
| Connector & Contact Terminates To | Printed Circuit Board |
| Number of Positions | 4 |
| Number of Loaded Positions | 4 |
| PCB Thickness (Recommended) | .063 |
| Connectors & Connector Components Type | Connector |
| TE Internal Number | 1-1705949-1 |
| PCB Mount Orientation | Right Angle |
| Connector System | Cable-to-Board |
| Connector Height | .453 |
| Housing Color | Black |
| Contact Underplating Material | Nickel |
| Contact Base Material | Phosphor Bronze |
| Connector Mounting Type | Board Mount |
| Operating Temperature Range | -40 – 70 |
| Shielded | No |
| Mating Entry Location | Side |
| Port Matrix Configuration | 1 x 1 |
| Packaging Method | Box & Tray |
| Packaging Quantity | 290 |
| Keyed | No |
| 端子の下地めっきの材料 | Nickel |
| Contact Mating Area Plating Material | Gold Flash |
| Panel Mount Feature Type | Panel Stops |
| RoHS | True |
| Connector Contact Density | Standard |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Modular Jacks & Plugs Products | RJ Type Jacks & Plugs |
| Modular Connector Style | Jack |
| Performance Category | Cat 3 |
| UL Flammability Rating | UL 94V-0 |
| Panel Mount Feature | Without |
| Contact Current Rating (Max) (A) | 1.5 |
| Connector Profile | Low |
| PCB Contact Termination Area Plating Material | Tin |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Ways | 4P4C |
| Orientation | Right Angle |
| Mounting Type | Through Hole |
| Series | 1-1705949 |
| Length | 11.2 (mm) |
| Depth | 18.1 (mm) |
| Ethernet Connector Type | RJ22 Connector |
| Contact Plating | Gold over Nickel |
| Gender | Female |
| Lan Category | Cat3 |
| Contact Material | Phosphor Bronze |
