1-1721150-3
General Purpose Relay SPDT (1 Form C) 12VDC Coil Through Hole
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapEDA?
SnapEDA is a free library of symbols & footprints for the 1-1721150-3 by TE Connectivity Potter & Brumfield Relays and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 24 hours!
More
Relevant part with 2D models
| Verification | Issues | Specs |
Specifications for the 1-1721150-3
| Part Name | 1-1721150-3 |
| Manufacturer | TE Connectivity |
| Insulation Initial Dielectric Between Contacts & Coil | 1500 |
| Product Weight | .335 |
| Coil Special Features | UL Coil Insulation Class F |
| Contact Limiting Making Current (A) | 10 |
| Height Class (Mechanical) | 15 – 16 |
| Product Width | 15.5 |
| Contact Material | AgZnO |
| Coil Power Rating DC | 360 |
| Contact Limiting Continuous Current (A) | 10 |
| Contact Switching Voltage (Max) (V) | 28 |
| Coil Resistance | 400 |
| Contact Current Class (A) | 16 |
| Contact Arrangement | 1 Form C (CO) |
| Contact Voltage Rating (V) | 28 |
| Contact Number of Poles | 1 |
| Insulation Clearance Between Contact & Coil | .093 |
| TE Internal Number | 1-1721150-3 |
| Product Height | 15.8 |
| Insulation Initial Dielectric Between Coil & Contact Class | 1000 – 1500 |
| Width Class (Mechanical) | 12 – 16 |
| Terminal Type | PCB-THT |
| Relay Mounting Type | Printed Circuit Board |
| Product Length | .748 |
| Insulation Clearance Class | 0 – 2.5 |
| Coil Voltage Rating (V) | 12 |
| Packaging Method | Box & Tube |
| Environmental Ambient Temperature (Max) | 185 |
| Power Relay Type | Standard |
| Coil Magnetic System | Monostable, DC |
| Environmental Ambient Temperature Class | 70 – 85 |
| Length Class (Mechanical) | 16 – 20 |
| Contact Limiting Short-Time Current (A) | 10 |
| Contact Limiting Breaking Current (A) | 10 |
| Coil Power Rating Class | 300 – 400 |
| Contact Current Rating (Max) (A) | 10 |
| Insulation Creepage Between Contact & Coil | .125 |
| Environmental Category of Protection | RTIII |
| Insulation Initial Dielectric Between Open Contacts | 750 |
| Insulation Creepage Class | 3 – 5.5 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
