1-2301994-0
Connector, Modular, 8-Position, Cat6, RJ45 Jack, Shielded, Industrial Series | TE Connectivity 1-2301994-0
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-2301994-0 by TE Connectivity AMP Connectors and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-2301994-0
| Part Name | 1-2301994-0 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| LED Color (Top Left) | None |
| LED Color (Bottom Left) | Green |
| LED Color (Top Right) | None |
| Port Configuration | Single Port |
| UL Flammability Rating | UL 94V-0 |
| Housing Material | LCP (Liquid Crystal Polymer) |
| PCB Ground Tab Location | 3.05 |
| Shield Panel Ground Type | Shield has bottom panel grounds. |
| Insulator Material | LCP |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Boardlock |
| Number of Loaded Positions | 8 |
| Grounding Options | PCB and Panel Ground |
| Number of PCB Ground Tabs | 2 |
| Connectors & Connector Components Type | Connector |
| TE Internal Number | 1-2301994-0 |
| PCB Mount Orientation | Right Angle |
| Status Indicator | LED |
| Connector Height | 13.63 |
| Housing Color | Black |
| Contact Underplating Material | Nickel |
| Connector Profile | Standard |
| Contact Base Material | Copper Alloy |
| Panel Ground Location | Top and Side |
| Operating Temperature Range | -40 – 85 |
| Shielded | Yes |
| Mating Entry Location | Side |
| Data Rate | 1000 |
| Packaging Method | Reel |
| LED Color (Bottom Right) | Yellow |
| Packaging Quantity | 80 |
| Keyed | No |
| Sealable | No |
| 端子の下地めっきの材料 | Nickel |
| Number of Positions | 8 |
| Contact Mating Area Plating Material | Gold over Nickel |
| Modular Jack & Plug Interface Type | RJ45 with Integrated Magnetics |
| Connector Contact Density | Standard |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Boardlock Material | LCP |
| Modular Jacks & Plugs Products | RJ Type Jacks & Plugs |
| Modular Connector Style | Jack |
| Shield Material | Brass |
| Performance Category | Cat 5e |
| Modular Jack Latch Orientation | Standard - Latch Down |
| Shield Plating Finish | Matte |
| Contact Mating Area Plating Material Thickness | .76 |
| Number of Panel Ground Tabs | 6 |
| Shield Plating Material | Nickel |
| Housing Material Temperature | 260 |
| Port Matrix Configuration | 1 x 1 |
| PCB Contact Termination Area Plating Material | Tin |
| PCB Termination Area Plating Finish | Matte |
| Packaging Reel Diameter | 33 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
