1-2301994-1
Conn RJ-45 RCP 8 POS 1.27mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 5e T/R
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-2301994-1 by TE Connectivity AMP Connectors and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-2301994-1
| Part Name | 1-2301994-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| LED Color (Top Left) | Green/Orange |
| LED Color (Bottom Left) | None |
| LED Color (Top Right) | Yellow |
| Port Configuration | Single Port |
| Panel Ground Location | Top and Side |
| Housing Material | LCP (Liquid Crystal Polymer) |
| PCB Ground Tab Location | 0 |
| Shield Panel Ground Type | Shield has bottom panel grounds. |
| Insulator Material | LCP |
| Modular Jacks & Plugs Products | RJ Type Jacks & Plugs |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Boardlock |
| Number of Loaded Positions | 8 |
| Grounding Options | PCB and Panel Ground |
| UL Flammability Rating | UL 94V-0 |
| Connectors & Connector Components Type | Connector |
| TE Internal Number | 1-2301994-1 |
| PCB Mount Orientation | Right Angle |
| Status Indicator | LED |
| Connector Height | .445 |
| Housing Color | Black |
| Contact Underplating Material | Nickel |
| Contact Base Material | Copper Alloy |
| Port Matrix Configuration | 1 x 1 |
| Operating Temperature Range | -40 – 85 |
| Shielded | Yes |
| Mating Entry Location | Side |
| Data Rate | 1000 |
| Packaging Method | Reel |
| Boardlock Material | LCP |
| Packaging Quantity | 80 |
| Keyed | No |
| 端子の下地めっきの材料 | Nickel |
| Number of Positions | 8 |
| Contact Mating Area Plating Material | Gold over Nickel |
| Modular Jack & Plug Interface Type | RJ45 with Integrated Magnetics |
| RoHS | True |
| Connector Contact Density | Standard |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| LED Color (Bottom Right) | None |
| Number of PCB Ground Tabs | 2 |
| Modular Connector Style | Jack |
| Shield Material | Brass |
| Performance Category | Cat 5e |
| PCB Termination Area Plating Finish | Matte |
| Modular Jack Latch Orientation | Inverted - Latch Up |
| Shield Plating Finish | Matte |
| Contact Mating Area Plating Material Thickness | 30 |
| Number of Panel Ground Tabs | 4 |
| Shield Plating Material | Nickel |
| Housing Material Temperature | 260 |
| Connector Profile | Low |
| PCB Contact Termination Area Plating Material | Tin |
| Sealable | No |
| Packaging Reel Diameter | 33 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Ways | 8 |
| Orientation | Right Angle |
| Mounting Type | PCB Mount |
| Ip Rating | IP20 |
| Gender | Female |
| Shield Type | Nickel Plated Brass |
| Series Number | 2031994 |
| Length | 19.75 (mm) |
| Width | 21.5 (mm) |
| Depth | 13.8 (mm) |
| Ethernet Connector Type | RJ45 Connector |
| Number Of Ports | 1 x 1 |
| Series | 1-2301994 |
| Contact Plating | Gold over Nickel |
| Lan Category | Cat6 |
| Contact Material | Copper Alloy |
