1-530785-6
BOX PIN HDR ASSY 10 PS 075 CL
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-530785-6 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-530785-6
| Part Name | 1-530785-6 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarized |
| Centerline (Pitch) | 1.9 |
| Termination Method to Printed Circuit Board | Straddle Mount |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Mounting Hole |
| PCB Mount Retention | With |
| PCB Thickness (Recommended) | .054 – .07 |
| Termination Post & Tail Length | .125 |
| PCB Connector Assembly Type | PCB Mount Header |
| Mating Post Length | .198 |
| TE Internal Number | 1-530785-6 |
| PCB Mount Orientation | Right Angle |
| Connector Height | .5 |
| Number of Rows | 2 |
| Housing Color | Blue |
| Header Type | Shrouded |
| Contact Base Material | Brass |
| Assembly Process Feature | None |
| Operating Temperature Range | -65 – 125 |
| Packaging Method | Package |
| Packaging Quantity | 1 |
| Number of Positions | 10 |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold |
| RoHS | No |
| Housing Material | Diallyl Phthalate |
| Sealable | No |
| PCB Contact Termination Area Plating Material | Tin-Lead |
| Post Size | .15 x .76 |
| Contact Mating Area Plating Material Thickness | 50 |
| Row-to-Row Spacing | 3.175 |
| Contact Current Rating (Max) (A) | 3 |
| Contact Type | Pin |
| Stackable | No |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
