1-5353188-1
Pin Connector .6FHP08H,160,S,GIG,08/Sn,TR,NSYes 160 POS
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-5353188-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-5353188-1
| Part Name | 1-5353188-1 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarization |
| Centerline (Pitch) | .6 |
| Circuit Application | Signal |
| UL Flammability Rating | UL 94V-0 |
| Housing Material | High Temperature Thermoplastic |
| Ground Component Type | Grounding Contact |
| Insulation Resistance | 2 |
| Operating Voltage (V) | 50 |
| PCB Mount Alignment Type | Locating Posts |
| Number of Positions | 160 |
| PCB Mount Retention Type | Solder Peg |
| PCB Mount Retention | With |
| PCB Thickness (Recommended) | .2 |
| Contact Current Rating (Max) (A) | .5 |
| Mating Post Length | 1 |
| TE Internal Number | 1-5353188-1 |
| PCB Mount Orientation | Vertical |
| Connector System | Board-to-Board |
| Connector Height | 8 |
| Number of Rows | 2 |
| Housing Color | Black |
| Contact Base Material | Copper Alloy |
| Connector Mounting Type | Board Mount |
| PCB Contact Termination Area Plating Material Thickness | 1 |
| Dielectric Withstanding Voltage (Max) (V) | 200 |
| Operating Temperature Range | -40 – 85 |
| Packaging Method | Reel |
| Packaging Quantity | 600 |
| Contact Layout | Inline |
| Connector & Contact Terminates To | Printed Circuit Board |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Termination Method to Printed Circuit Board | Surface Mount |
| Board-to-Board Configuration | Mezzanine |
| PCB Contact Termination Area Plating Material | Tin |
| PCB Mount Alignment | With |
| Stack Height | .63 |
| Contact Mating Area Plating Material Thickness | 7.874 |
| PCB マウント アラインメント タイプ | Locating Posts |
| PCB Connector Assembly Type | PCB Mount Header |
| High Temperature Compatible | Yes |
| Contact Type | Pin |
| Stackable | Yes |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 1-5353188-1 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| Avnet America |
|
|
Visit Site | |
| Boersig GmbH |
|
1 x $12.60
|
Visit Site | |
| Chip One Stop |
597
|
1,200 x $8.74
|
Visit Site | |
| Conrad |
597
|
|
Visit Site | |
| Heilind Americas |
90
|
|
Visit Site | |
| Interstate Connecting Components |
30
|
|
Visit Site | |
| Newark |
597
|
1 x $13.22
|
Visit Site | |
| Powell Electronics |
394
|
|
Visit Site | |
| Sager |
|
600 x $11.82
|
Visit Site |
