1-962842-1
Rectangular Power Contact, JPT Series, Gold Plated Contacts, Bronze, Pin, Crimp, 17 AWG
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1-962842-1 by TE Connectivity / AMP and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1-962842-1
| Part Name | 1-962842-1 |
| Manufacturer | TE Connectivity / AMP |
| Sealable | No |
| Wire Type | Copper |
| Operating Temperature Range | -40 – 130 |
| Terminal & Splice Type | Tab |
| Wire Insulation Diameter | 2.1 – 2.9 |
| Packaging Method | Reel |
| TE Internal Number | 1-962842-1 |
| Wire Size Search | 1.3 |
| Crimp Type | F-Crimp |
| Agency/Standard | LV214 |
| Interface Plating | Tin (Sn) |
| Contact Termination Area Plating Material | Tin (Sn) |
| Terminal Transmits | 25 – 40 A (Power) |
| Primary Locking Feature | Locking Lance |
| Mating Tab Thickness | .8 |
| Termination Method | Crimp |
| Packaging Quantity | 3500 |
| Receptacle Style | 180° |
| Wire Size | 1 – 2.5 |
| Typical Current Rating (A) | 30 |
| Mating Tab Width | .11 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | |
| Diameter | 2.9 (mm) |
| Type | Tab |
| Current Rating (A) | 40 (A) |
| Contact Plating | Tin |
| Mounting Type | Cable Mount |
| Series | AMP |
| Termination Method | Crimp |
| Width | 2.8 (mm) |
| Number Of Rows | 1 |
| Minimum Operating Temperature | -40 (°C) |
| Gender | Female |
| Corded | No |
| Number Of Contacts | 1 |
| Maximum Operating Temperature | +130 (°C) |
| Contact Material | Copper |
No issues have been reported for the 1-962842-1
