PCB Terminal Push-In 5.08mm 12AWG 400V 32A 3 Position Combicon Control Series | Phoenix Contact 1017504
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1017504 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1017504
| Part Name | 1017504 |
| Manufacturer | Phoenix Contact |
| Category | Connectors |
| Min. Conductor Cross-section (flexible Wire With Ferrule Without Plastic Collar) | 0.2 |
| Max. Operating Temperature | 105 |
| Max. Line Cross Section, Rigid | 4 |
| Width | 16.04 |
| GTIN | 4055626501383 |
| Min. Operating Temperature | -40 |
| Min. Line Cross Section, Flexible | 0.2 |
| Product Description | PCB terminal block |
| Gtin (ean) Code | 4055626501383 |
| Internal Article Number | 1017504 |
| Number Of The Executions Of The Housing Parts | 0 |
| Max. Line Cross Section, Flexible | 4 |
| Depth | 18 |
| Manufacturer Product Designation | PCB terminal block |
| RoHS | True |
| Assembly Type | Print mounting |
| Flammability Rating Of The Insulating Material (based On Ul 94) | V0 |
| Material Of Insulation | PA |
| Product Article Number Of Manufacturer | 1017504 |
| Net Weight | 0.00656 |
| Height | 22.5 |
| Min. Line Cross Section, Rigid | 0.2 |
| Application Standards | IECÂ 60947-7-4 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Series | TDPT 2.5/ 3-SP-5.08 |
| Current Rating (A) | 32 (A) |
| Mounting Type | Through Hole |
| Voltage Rating (V) | 400 V |
| Gender | Female |
| Colour | Green |
| Material | Copper Alloy (Contact) |
| Termination Method | Screw |
| Width | 16.04 (mm) |
| Depth | 19 (mm) |
| Number Of Rows | 1 |
| Length | 18 (mm) |
| Pitch | 5.08 (mm) |
| Number Of Contacts | 3 |
| Type | PCB Terminal Block |
| Body Orientation | Straight |
Inventory for the 1017504 by Phoenix Contact from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
1,267
|
|
Visit Site | |
|
★ Featured
|
1,368
|
1 x $1.09
|
Visit Site | |
| Onlinecomponents |
500
|
|
Visit Site | |
| RS Americas |
20
|
|
Visit Site | |
| Verical |
100
|
|
Visit Site |
