104479-8
Headers, SKT 24-20 CU/SN Reel of 15000 | TE Connectivity 104479-8
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 104479-8 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 104479-8
| Part Name | 104479-8 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Dielectric Withstanding Voltage (V) | 750 |
| Insulation Resistance | 5000 |
| Crimp Area Plating Thickness | 100 – 200 |
| Operating Voltage (V) | 300 |
| Connector & Contact Terminates To | Wire & Cable |
| Wire Contact Termination Area Plating Material | Tin |
| TE Internal Number | 104479-8 |
| Termination Method to Wire & Cable | Crimp |
| Termination Resistance | 12 |
| Contact Base Material | Copper Alloy C7025 |
| Wire Insulation Support | With |
| Contact Transmits (Typical) | Signal (Data)/Power |
| Operating Temperature Range | -65 – 105 |
| Insulation Diameter | .025 – .06 |
| Packaging Method | Strip |
| Packaging Quantity | 15000 |
| Contact Termination Area Plating Material | Tin |
| Applied Pressure | Standard |
| Contact Mating Area Plating Material | Tin |
| RoHS | True |
| Approved Standards | UL E28476 |
| Product Type | Contact |
| Contact Current Rating (Max) (A) | 3 |
| Contact Mating Area Plating Thickness | 100 – 200 |
| Contact Type | Socket |
| Wire/Cable Type | Discrete Wire |
| Wire Size | .2 – .6 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
