SMD female connector Nominal current at 20C: 1.7 A Test voltage: 500 V AC | Phoenix Contact 1061662
Availability: Out of Stock
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1061662 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1061662
| Part Name | 1061662 |
| Manufacturer | Phoenix Contact |
| Material Of The Contact Coat | Gold |
| Assembly Type | SMD soldering |
| Material Of Insulation | LCP |
| Flammability Rating Of The Insulating Material (based On Ul 94) | V0 |
| Product Article Number Of Manufacturer | 1061662 |
| Type Of Pcb Contacting | SMD connection |
| Product Description | SMD female connectors |
| Pole Number | 32 |
| Category | Connectors |
| Height | 5.45 |
| Width | 17.58 |
| Depth | 7.3 |
| GTIN | 4055626713496 |
| Type Of Interlock | without |
| Rated Current (A) | 1.7 |
| Manufacturer Product Designation | SMD female connectors |
| Color Of Housing | black |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the 1061662
If you experienced any issues with the symbol or footprint, please report it.
