130171
Ring terminal; M5; Ø: 5.2mm; 3÷6mm2; crimped; for cable; insulated
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 130171 by TE Connectivity / AMP and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 130171
| Part Name | 130171 |
| Manufacturer | TE Connectivity / AMP |
| Stripe Color | Yellow |
| Insulation Sleeve Color | Yellow |
| Wire Insulation Diameter (Max) | 6.35 |
| Inspection Slot | No |
| Operating Temperature Range | 105 |
| Terminal & Splice Type | Ring Tongue |
| Packaging Method | Loose Piece |
| Barrel Type | Closed Barrel |
| Wire Insulation Diameter | 3.81 – 6.35 |
| Packaging Quantity | 500 |
| Support Style | Non - Insulation Support |
| Terminal Orientation | Straight |
| Wire/Cable Type | Regular Wire |
| Terminal Angle | Straight |
| Current Rating (A) | 1 |
| Shape Description | RING-041 |
| Insulated | Yes |
| Wire Size | 12 – 10 |
| Plating Material | Tin |
| Heavy Duty | No |
| Government Qualified | No |
| TE Internal Number | 130171 |
| Stud Size | M5 |
| Voltage (Max) (V) | 300 |
| Stud Diameter | 5.25 |
| Overall Length | 27.68 |
| Number of Holes | 1 |
| Tongue Thickness | .79 |
| Sealable | No |
| Wire Insulation Support | With |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Minimum Wire Size Mm | 2.6 (mm²) |
| Maximum Wire Size Mm | 6.6 (mm²) |
| Series | PIDG |
| Colour | Yellow |
| Minimum Wire Size Awg | 12 (AWG) |
| Stud Size | M5 |
| Inner Ring Diameter | 5.25 (mm) |
| Outer Ring Diameter | 9.52 (mm) |
| Contact Plating | Tin |
| Overall Length | 27.7 (mm) |
| Insulation | Insulated |
| Maximum Wire Size Awg | 10 (AWG) |
| Contact Material | Copper |
