1376347-1
Contact,crimp,receptacle,preTin,20-16awg | TE Connectivity 1376347-1
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1376347-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1376347-1
| Part Name | 1376347-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Circuit Application | Power |
| Number of Power Positions | 0 |
| Operating Voltage (V) | 300 |
| Connector & Contact Terminates To | Printed Circuit Board |
| Termination Method to Wire & Cable | Crimp |
| TE Internal Number | 1376347-1 |
| Connector System | Wire-to-Board |
| Number of Rows | 2 |
| Number of Signal Positions | 0 |
| Product Type | Connector |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
| Operating Temperature Range | -40 – 221 |
| Packaging Method | Reel |
| Housing Type | Plug |
| Packaging Quantity | 5000 |
| Contact Mating Area Plating Material | Pre-Tin |
| RoHS | True |
| Sealable | No |
| Contact Retention | Without |
| Contact Current Rating (Max) (A) | 8 |
| Contact Mating Area Plating Thickness | 10 |
| Contact Type | Socket |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Wire Size | 1.3 – .51 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | |
| Series | 5.0 Power Key |
| Minimum Operating Temperature | -30 (°C) |
| Minimum Wire Size (Mm²) | 0.5 (mm²) |
| Minimum Wire Size (Awg) | 20 (AWG) |
| Termination Method | Crimp |
| Maximum Wire Size (Mm²) | 1.25 (mm²) |
| Maximum Wire Size (Awg) | 16 (AWG) |
| Contact Plating | Tin |
| Gender | Female |
| For Use With | 5.0 Power Key and Grace Inertia Connector Housings |
| Maximum Operating Temperature | +105 (°C) |
| Contact Material | Copper Alloy |
