1410142-2
Conn Backplane RCP 144 POS 1.8mm Press Fit ST Thru-Hole VITA 46 Tube
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1410142-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1410142-2
| Part Name | 1410142-2 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarization |
| Centerline (Pitch) | 1.8 |
| Circuit Application | Power & Signal |
| Connector & Contact Terminates To | Printed Circuit Board |
| Board | Switch Slot |
| Connector Style | Receptacle |
| Number of Positions | 144 |
| TE Internal Number | 1410142-2 |
| PCB Mount Orientation | Vertical |
| Connector System | Board-to-Board |
| Number of Rows | 9 |
| Card Slot Centerline | 20.3 |
| Connector Mounting Type | Board Mount |
| Number of Columns | 16 |
| Operating Temperature Range | -67 – 221 |
| Mating Alignment | With |
| RoHS | True |
| Board-to-Board Configuration | Vertical |
| Shrouded | Unshrouded |
| Row-to-Row Spacing | 1.8 |
| Contact Current Rating (Max) (A) | 1 |
| Guide Location | Right |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
