1424177
SnapVerified
Cat6a Unshielded Straight Cat6 Ethernet Cable Assembly | Phoenix Contact 1424177
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1424177 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1424177
| Part Name | 1424177 |
| Manufacturer | Phoenix Contact |
| Material Of The Contact Coat | Gold |
| Category | Wire & Cable |
| Min. Operating Temperature | -25 |
| Product Article Number Of Manufacturer | 1424177 |
| Product Description | Device connector rear mounting |
| Shield Connection Present | True |
| Pole Number | 8 |
| Material Of Housing | Zink print cast |
| Max. Operating Temperature | 85 |
| Construction Form Of The Plug Connector | M12 |
| Rated Current (A) | 0.5 |
| Degree Of Protection (ip), Mounted | IP67 |
| Flammability Rating Of The Insulating Material (based On Ul 94) | V0 |
| Type Of Plug-in Contact, Outside | Female (socket) |
| RoHS | True |
| Max. Ambient Temperature | 85 |
| Manufacturer Product Designation | Device connector rear mounting |
| Insertion Cycles, Min. | 100 |
| GTIN | 4046356692656 |
| Degree Of Soiling | 3 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Plug Socket | Socket |
| Ip Rating | IP67 |
| Series | SACC |
| Body Orientation | Straight |
| Coding | X |
| Shielded Unshielded | Unshielded |
| Connector Size | M16 |
Inventory for the 1424177 by Phoenix Contact from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
2,645
|
1 x $32.47
|
Visit Site | |
| Conrad |
|
|
Visit Site | |
| Farnell UK |
490
|
|
Visit Site | |
| Newark |
30
|
|
Visit Site | |
| Onlinecomponents |
111
|
|
Visit Site | |
| Sager |
|
1 x $32.47
|
Visit Site | |
| TTI Europe |
|
|
Visit Site | |
| Verical |
107
|
|
Visit Site | |
| element14 Singapore |
490
|
|
Visit Site |
No issues have been reported for the 1424177
