15166-0215
20 Way Flat Ribbon Cable, 0.152m, Series Premo-Flex | Molex Incorporated 15166-0215
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 15166-0215 by Molex and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 15166-0215
| Part Name | 15166-0215 |
| Manufacturer | Molex |
| Category | Wire & Cable |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Ways | 20 |
| Voltage Rating (V) | 60 V ac |
| Series | Premo-Flex |
| Operating Temperature Range | -40 → +105 °C |
| Width | 0.50 mm |
| Length | 152 (mm) |
| Pitch | 0.5 (mm) |
| Ribbon Cable Type | FFC |
| Terminated Unterminated | Unterminated |
