1623155-1
220 kOhms ±1% 0.125W, 1/8W Chip Resistor 0805 (2012 Metric) - Thick Film
Availability: In Stock
Package Type: 0805
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1623155-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1623155-1
| Part Name | 1623155-1 |
| Manufacturer | TE Connectivity |
| Mount Style | Surface Mount |
| Dimensions | 2 x 1.25 x .55 |
| Voltage Rating (V) | 150 |
| Number of Terminations | 2 |
| Resistor Type | General Purpose Resistor |
| Package | 0805 |
| Resistance Range | 1kΩ – 1MΩ |
| TE Internal Number | 1623155-1 |
| Temperature Coefficient | ±100 |
| Resistance | 220K |
| Packaging Method | Taped & Reeled |
| Number of Resistors | 1 |
| Element Type | Thick Film |
| Termination Type | Solder |
| Power Rating | .125 |
| Product Type | Fixed Resistor |
| Tolerance | 1% |
| Size Code | 0805 |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet |
Inventory for the 1623155-1 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| Mouser |
|
N/A | Visit Site | |
| Onlinecomponents |
102,000
|
|
Visit Site | |
| Verical |
10,000
|
10,000 x $0.007
|
Visit Site |
No issues have been reported for the 1623155-1
