170359-1
MIN-UMNL CONT STP-ID, UNIV M-N-L PIN 26-22 AWG | TE Connectivity 170359-1
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 170359-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 170359-1
| Part Name | 170359-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Contact Retention Within Housing | With |
| Wire Type | Stranded |
| Circuit Application | Power |
| Wire/Cable Type | Discrete Wire |
| Contact Termination Area Plating Thickness | 31.49 |
| Crimp Area Plating Thickness | .8 |
| Operating Voltage (V) | 600 |
| For Use With | Plug or Cap Housing |
| Connector & Contact Terminates To | Wire & Cable |
| Wire Contact Termination Area Plating Material | Tin |
| VDE Tested | No |
| CSA File Number | LR 7189 |
| TE Internal Number | 170359-1 |
| UL Rating | Recognized |
| Connector System | Wire-to-Wire |
| Contact Orientation | Straight |
| Contact Base Material | Brass |
| Wire Insulation Support | Without |
| UL File Number | E28476 |
| Operating Temperature Range | -20 – 105 |
| For Multiple Crimp | No |
| Packaging Method | Reel |
| Packaging Quantity | 6000 |
| Agency/Standard | CSA |
| Contact Termination Area Plating Material | Tin |
| Accepts Wire Insulation Diameter Range | 1.19 – 1.75 |
| Contact Mating Area Plating Material | Tin |
| CSA Rating | Certified |
| RoHS | True |
| Product Type | Contact |
| Connector Mounting Type | Cable Mount (Free-Hanging) |
| Contact Current Rating (Max) (A) | 7 |
| Contact Mating Area Plating Thickness | .8 |
| Termination Type | Crimp |
| Mating Pin Diameter | 1 |
| Contact Type | Pin |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Wire Size | .12 – .35 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Minimum Operating Temperature | -20 (°C) |
| Maximum Contact Resistance | 10 (mΩ) |
| Minimum Wire Size (Mm²) | 0.1 (mm²) |
| Series | Mini-Universal MATE-N-LOK |
| Maximum Wire Size (Mm²) | 0.35 (mm²) |
| For Use With | Mini-Universal MATE-N-LOK Connector Housing |
| Gender | Male |
| Maximum Wire Size (Awg) | 22 (AWG) |
| Contact Plating | Tin |
| Termination Method | Crimp |
| Minimum Wire Size (Awg) | 26 (AWG) |
| Maximum Operating Temperature | +105 (°C) |
| Contact Material | Brass |
Inventory for the 170359-1 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
8,651
|
|
Visit Site | |
|
★ Featured
|
74,920
|
17,965 x $0.02
|
Visit Site | |
| Arrow Europe |
318,000
|
|
Visit Site | |
| Avnet America |
36,000
|
6,000 x $0.03
|
Visit Site | |
| Boersig GmbH |
426,000
|
1 x $0.05
|
Visit Site | |
| Buerklin |
|
6,000 x $0.06
|
Visit Site | |
| CoreStaff |
24,000
|
|
Visit Site | |
| Dalroad Norslo |
6,000
|
|
Visit Site | |
| Farnell UK |
162,000
|
|
Visit Site | |
| Heilind Europe |
90,000
|
|
Visit Site | |
| Newark |
3,320
|
1 x $0.09
|
Visit Site | |
| Onlinecomponents |
60,000
|
|
Visit Site | |
| Powell Electronics |
24
|
|
Visit Site | |
| Sager |
|
24,000 x $0.06
|
Visit Site | |
| TE Store |
32,006
|
|
Visit Site | |
| TME |
180,000
|
|
Visit Site | |
| TTI Europe |
30,000
|
6,000 x $0.04
|
Visit Site | |
| Verical |
186,000
|
6,000 x $0.07
|
Visit Site | |
| element14 Singapore |
9,979
|
|
Visit Site |
No issues have been reported for the 170359-1
If you experienced any issues with this part, please report it.
