173630-2
Contact SKT Crimp ST Cable Mount Strip
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 173630-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 173630-2
| Part Name | 173630-2 |
| Manufacturer | TE Connectivity |
| Receptacle Style | 180° |
| Sealable | No |
| Wire Type | Copper |
| Operating Temperature Range | -22 – 221 |
| Terminal & Splice Type | Receptacle |
| Wire Insulation Diameter | 1.4 – 1.9 |
| Packaging Method | Reel |
| TE Internal Number | 173630-2 |
| Wire Size Search | .3 |
| Crimp Type | F-Crimp |
| Interface Plating | Gold (Au) |
| Contact Termination Area Plating Material | Gold (Au) |
| Primary Locking Feature | Clean Body |
| Mating Tab Thickness | .025 |
| Typical Current Rating (A) | 4 |
| Termination Method | Crimp |
| Packaging Quantity | 4000 |
| Terminal Transmits | 0 – 24 A (Low Power) |
| Wire Size | .3 |
| RoHS | True |
| Mating Tab Width | .071 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet |
Inventory for the 173630-2 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| Avnet America |
|
|
Visit Site | |
| Farnell UK |
|
16,000 x $0.26
|
Visit Site | |
| Heilind Europe |
|
|
Visit Site | |
| Interstate Connecting Components |
|
32,000 x $0.25
|
Visit Site | |
| Newark |
|
5,000 x $0.28
|
Visit Site |
