1757321-2
Rcpt Assy, Size 2, Arinc 600, C2/71c1/13c2 , Connector
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1757321-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1757321-2
| Part Name | 1757321-2 |
| Manufacturer | TE Connectivity |
| Shell Plating Material | Electroless Nickel |
| Contact Arrangement (Module B) | 71C1 |
| Sealable | No |
| Contact Arrangement (Module A) | Blank (Dummy) |
| Keying | 1 |
| TE Internal Number | 1757321-2 |
| Contact Arrangement (Module C) | 13C2 |
| Tail Length | .122 |
| Clinch Nuts | Without |
| Release Style | Front |
| Shell Size | 2 |
| Product Type | Connector |
| Preloaded | Yes |
| RoHS | N |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 1757321-2 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
30 x $1172.69
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Chip One Stop |
5
|
|
Visit Site | |
| Heilind Americas |
|
30 x $1250.87
|
Visit Site | |
| Interstate Connecting Components |
|
30 x $1250.87
|
Visit Site | |
| Mouser |
|
30 x $1665.04
|
Visit Site | |
| Onlinecomponents |
6
|
|
Visit Site | |
| Powell Electronics |
3
|
1 x $1274.04
|
Visit Site | |
| Sager |
|
6 x $1447.77
|
Visit Site | |
| TME |
5
|
|
Visit Site | |
| TTI Americas |
|
|
Visit Site | |
| Verical |
5
|
1 x $1367.35
|
Visit Site |
No issues have been reported for the 1757321-2
If you experienced any issues with this part, please report it.
