1825027-8
Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 1.57N Thru-Hole Loose Piece/Bulk
Availability: In Stock
What is SnapEDA?
SnapEDA is a free library of symbols & footprints for the 1825027-8 by TE Connectivity ALCOSWITCH Switches and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 24 hours!
More
Relevant part with 2D models
| Verification | Issues | Specs | Pricing |
Specifications for the 1825027-8
| Part Name | 1825027-8 |
| Manufacturer | TE Connectivity |
| Ganged | With |
| Operating Function | NO |
| Low Profile | With |
| Temperature Rating | Standard |
| Button Width | 3.5 |
| ESD Grounding Terminal | Without |
| Actuator Color | Blue |
| Actuator Profile | Extended |
| Actuator Style | Round |
| Actuator Length | .128 |
| Illuminated | With |
| Number of Actuators | 1 |
| Contact Current Rating (A) | 50 |
| TE Internal Number | 1825027-8 |
| Snap Action | Without |
| Case Material | Nylon |
| Dust Proof | No |
| Body Style | Right Angle |
| Leg Style | Kinked |
| Contact Base Material | Copper Alloy |
| Support Bracket | With |
| Switch Height | 7 |
| Case Color | Black |
| Packaging Method | Loose Piece |
| Configuration (Pole-Throw) | Single Pole - Single Throw |
| Process Sealed | No |
| Mounting Angle | Right Angle |
| Product Type | Switch |
| Actuator Force | 160 |
| Mounting Type | Through Hole |
| Tactile Feel | With |
| Termination Type | Printed Circuit Board |
| Bushing Style | Unthreaded |
| Switch Contact Plating Material | Silver |
| Actuator Material | PBT |
| Tactile | Yes |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
