1845137
SnapVerified
Terminal Block, Header, Male Pins, 26 positions, 0.100" pitch, 6A, 150V, | Phoenix Contact 1845137
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1845137 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1845137
| Part Name | 1845137 |
| Manufacturer | Phoenix Contact |
| Category | Connectors |
| Assembly Type | SMD soldering |
| Material Of Insulation | LCP |
| Flammability Rating Of The Insulating Material (based On Ul 94) | V0 |
| Assembly | plugged-in |
| Product Article Number Of Manufacturer | 1845137 |
| Type Of Pcb Contacting | SMD connection |
| Product Description | PCB header |
| Pole Number | 13 |
| Certificate/approval | cULus Recognized, VDE Gutachten mit Fertigungsüberwachung |
| Height | 7.39 |
| Width | 37.6 |
| Depth | 12.26 |
| GTIN | 4046356964678 |
| Rated Current (A) | 6 |
| Manufacturer Product Designation | PCB header |
| Application Standards | IECÂ 61984 |
| Color Of Housing | black |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the 1845137
If you experienced any issues with the symbol or footprint, please report it.
