1888290-6
Socket Receptacle Connector .100 SRRA T-H, Latchg Flexstrip Recep 16 POS
Availability: In Stock
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1888290-6 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1888290-6
| Part Name | 1888290-6 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarization |
| Centerline (Pitch) | .1 |
| UL Flammability Rating | UL 94V-0 |
| Housing Material | Polyester - GF 30 |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention | Without |
| PCB Thickness (Recommended) | .062 |
| Termination Post & Tail Length | .1 |
| TE Internal Number | 1888290-6 |
| PCB Mount Orientation | Right Angle |
| Connector System | Wire-to-Board |
| Connector Height | 5.33 |
| Number of Rows | 1 |
| PCB Contact Termination Area Plating Material Thickness | 2.54 |
| Header Type | Shrouded |
| Contact Mating Area Plating Material Finish | Matte |
| Strain Relief | Without |
| Connector Mounting Type | Board Mount |
| Contact Shape | Square |
| Housing Color | Blue |
| Mating Retention | With |
| Connector Length | 42.16 |
| Packaging Method | Tube |
| Packaging Quantity | 12 |
| Contact Layout | Inline |
| Number of Positions | 16 |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Tin |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Contact Base Material | Copper Alloy |
| PCB Mount Alignment | Without |
| Mating Retention Type | Locking |
| PCB Connector Assembly Type | PCB Mount Receptacle |
| Contact Retention | Without |
| PCB Contact Termination Area Plating Material Finish | Matte |
| Contact Type | Socket |
| PCB Contact Termination Area Plating Material | Tin |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
