1903815-1
Conn, Data, USB, Recept, 2.0, 4 Pos, 2 Port, Rt Angle, A Ser, Gold/Nickel | TE Connectivity 1903815-1
Availability: In Stock
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1903815-1 by TE Connectivity AMP Connectors and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1903815-1
| Part Name | 1903815-1 |
| Manufacturer | TE Connectivity |
| Shell Plating Material | Tin over Nickel |
| Category | Connectors |
| Mounting Location | Top |
| Shell Plating Finish | Bright |
| Pick and Place | None |
| Packaging Method | Tray |
| Tail Length | 2.84 |
| Packaging Quantity | 70 |
| Housing Material | Thermoplastic |
| Number of Ports | 2 |
| Contact Termination Type | Through Hole |
| Contact Mating Area Plating Material | Gold over Nickel |
| Connector Style | Receptacle |
| Number of Positions | 4 |
| PCB Mount Retention Type | Kinked Legs |
| Industry Standard | USB 2.0 |
| Locking Feature | Without |
| PCB Thickness (Recommended) | 1.57 |
| Orientation | Right Angle |
| TE Internal Number | 1903815-1 |
| Connector & Contact Terminates To | Printed Circuit Board |
| Contact Mating Area Plating Thickness | .76 |
| Housing Color | Black |
| Termination Method | Solder |
| LED | Without |
| Product Type | Connector |
| Size | Standard |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 1903815-1 by TE Connectivity AMP Connectors from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
7,298
|
|
Visit Site |
No issues have been reported for the 1903815-1
