19418-0002
MX150L Series 5.84mm Pitch 8 Way 2 Row Female Straight PCB Housing 19418 | Molex Incorporated 19418-0002
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 19418-0002 by Molex and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 19418-0002
| Part Name | 19418-0002 |
| Manufacturer | Molex |
| Category | Connectors |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Mounting Type | Cable Mount |
| Gender | Female |
| Body Orientation | Straight |
| Pitch | 5.84 (mm) |
| Housing Material | PBT |
| Width | 28.86 (mm) |
| Length | 33.83 (mm) |
| Number Of Rows | 2 |
| Series | MX150L |
| For Use With | MX150L 8 Circuit Receptacle |
| Number Of Contacts | 8 |
