Phoenix Contact 1944615 MSTBVA 2,5/ 4-G-RN
Availability: Out of Stock
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1944615 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1944615
| Part Name | 1944615 |
| Manufacturer | Phoenix Contact |
| Category | Connectors |
| Assembly Type | Wave soldering |
| Flammability Rating Of The Insulating Material (based On Ul 94) | V0 |
| Assembly | with cams |
| Product Article Number Of Manufacturer | 1944615 |
| Material Of Insulation | PBT |
| Product Description | PCB header |
| Pole Number | 4 |
| Certificate/approval | CSA, cULus Recognized, VDE Zeichengenehmigung |
| Height | 15.9 |
| Width | 25.9 |
| Depth | 8.57 |
| GTIN | 4017918890896 |
| Rated Current (A) | 12 |
| Manufacturer Product Designation | PCB header |
| Application Standards | IEC 61984 |
| Color Of Housing | green |
