19S202-40ML5
RF Connector, SMP Right Angle Plug PCB, 7.4mm, Limited Detent, SMD, SMP Series | Rosenberger 19S202-40ML5
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 19S202-40ML5 by Rosenberger and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 19S202-40ML5
| Part Name | 19S202-40ML5 |
| Manufacturer | Rosenberger |
| Category | Connectors |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Mating Type | Snap On |
| Mounting Type | PCB Mount |
| Gender | Male |
| Body Orientation | Right Angle |
| Coaxial Connector Type | SMP Connector |
| Contact Plating | Gold |
| Termination Method | Solder |
| Operating Frequency | 0 to 40 (GHz) |
| Impedance | 50 (Ω) |
| Contact Material | Copper Zinc Alloy |
