1PGSMB5946
DO-214AA (SMB), 3000mW, 5%, Zener Diode
Availability: Out of Stock
Package Type: SMD-2
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 1PGSMB5946 by taiwan and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 1PGSMB5946
| Part Name | 1PGSMB5946 |
| Manufacturer | Taiwan Semiconductor |
| Minimum Zener Voltage (V) | 71.25 |
| Zener Voltage (V) | 75.0 |
| Maximum Zener Voltage (V) | 78.75 |
| Case Package | DO-214AA (SMB) |
| IR at VR in V | 56.0 |
| Zener Impedance at IZT in ohms | 140.0 |
| Zener Test Current (A) | 0.005 |
| Zener Impedance at IZK in ohms | 2000.0 |
| AEC-Q compliant | True |
| Reverse Current at VR (A) | 1e-06 |
| Zener Voltage tolerance (V) | [-5.0, 5.0] |
| Power Dissipation | 3.0 |
| Zener Impedance at IZK in mA | 0.25 |
| Maximum Operating Junction Temperature | 175.0 |
| RoHS | True |
| Moisture Level | 1.0 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the 1PGSMB5946
