2-2340324-1
140 Position Female Connector Non Specified - Dual Edge Gold 0.024" (0.60mm) Black
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2-2340324-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2-2340324-1
| Part Name | 2-2340324-1 |
| Manufacturer | TE Connectivity AMP Connectors |
| Centerline (Pitch) | .023 |
| Circuit Application | Signal |
| Termination Method to Printed Circuit Board | Surface Mount |
| Connector Style | Receptacle |
| Connector & Contact Terminates To | Printed Circuit Board |
| Shell | Without |
| TE Internal Number | 2-2340324-1 |
| PCB Mount Orientation | Straddle Mount |
| Number of Rows | 2 |
| Contact Underplating Material | Nickel |
| Product Type | Connector |
| Connector Mounting Type | Board Mount |
| Industry Standard | Gen-Z |
| Operating Temperature Range | -67 – 185 |
| Connector Type | Card-Edge |
| Contact Base Material | Copper Alloy |
| Number of Positions | 140 |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| 端子の下地めっきの材料 | Nickel |
| Contact Mating Area Plating Material Thickness | .762 |
| Contact Current Rating (Max) (A) | 1.1 |
| Sliver Family | SFF-TA-1002 |
| PCB Contact Termination Area Plating Material | Tin |
| Sealable | No |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
