2-320576-2
Ring Terminal Connector 5/16 Stud Circular 12 AWG Crimp
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2-320576-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2-320576-2
| Part Name | 2-320576-2 |
| Manufacturer | TE Connectivity |
| Stripe Color | Yellow |
| Current Rating (A) | 1 |
| Wire Insulation Diameter (Max) | 5.08 |
| Military Part Class | Class I |
| Wire Insulation Diameter | 2.413 – 5.08 |
| Support Style | Insulation Restriction |
| Wire/Cable Type | Regular Wire |
| Terminal Angle | Straight |
| Insulated | Yes |
| Plating Material | Copper |
| TE Internal Number | 2-320576-2 |
| Voltage (Max) (V) | 300 |
| Stud Diameter | .312 |
| Overall Length | 1.392 |
| Sealable | No |
| Wire Insulation Support | With |
| Number of Holes | 1 |
| Operating Temperature Range | 221 |
| Terminal & Splice Type | Ring Tongue |
| Packaging Method | Box |
| Packaging Quantity | 500 |
| Terminal Orientation | Offset |
| Barrel Type | Closed Barrel |
| RoHS | True |
| Shape Description | RING-042 |
| Weight per Piece | 2.752 |
| Heavy Duty | No |
| Stud Size | M8 |
| Government Qualified | Yes |
| Tongue Thickness | .031 |
| Wire Size | 12 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Minimum Wire Size Mm | 2.6 (mm²) |
| Maximum Wire Size Mm | 6.6 (mm²) |
| Series | PIDG |
| Colour | Yellow |
| Minimum Wire Size Awg | 12 (AWG) |
| Stud Size | M8 |
| Inner Ring Diameter | 8.33 (mm) |
| Outer Ring Diameter | 13.48 (mm) |
| Contact Plating | Tin |
| Overall Length | 35.36 (mm) |
| Insulation | Insulated |
| Maximum Wire Size Awg | 10 (AWG) |
| Insulation Material | Nylon |
| Contact Material | Copper |
Inventory for the 2-320576-2 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
2,238
|
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Chip One Stop |
351
|
5,000 x $1.14
|
Visit Site | |
| Farnell UK |
3,092
|
|
Visit Site | |
| Heilind Europe |
|
|
Visit Site | |
| Newark |
3,092
|
|
Visit Site | |
| Powell Electronics |
233
|
|
Visit Site | |
| RS UK |
1,060
|
|
Visit Site | |
| TME |
351
|
|
Visit Site | |
| TTI Americas |
|
|
Visit Site | |
| element14 Singapore |
3,092
|
|
Visit Site |
No issues have been reported for the 2-320576-2
