2-829587-0
SnapVerified
MOD-2 PIN HDR.2X20P
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2-829587-0 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2-829587-0
| Part Name | 2-829587-0 |
| Manufacturer | TE Connectivity |
| Centerline (Pitch) | 2.54 |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Connector & Contact Terminates To | Printed Circuit Board |
| Number of Positions | 40 |
| PCB Mount Retention | Without |
| Termination Post & Tail Length | .126 |
| Mating Post Length | .232 |
| TE Internal Number | 2-829587-0 |
| PCB Mount Orientation | Vertical |
| Number of Rows | 2 |
| Housing Color | Green |
| Contact Base Material | Copper Tin |
| Contact Shape | Square |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Life Cycle Status | Factory Special Order |
| Housing Material | PBT GF |
| Post Size | .0248 |
| Stack Height | .728 |
| Row-to-Row Spacing | .1 |
| PCB Connector Assembly Type | PCB Mount Header |
| Contact Type | Pin |
| Stackable | Yes |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
