201580-1
Multimate Contact Socket Gold (30) Over Nickel (50) 24 to 20 AWG Brass 16 | TE Connectivity 201580-1
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 201580-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 201580-1
| Part Name | 201580-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Contact Retention Within Housing | With |
| Contact Mating Area Plating Thickness | 30 |
| Circuit Application | Signal |
| Packaging Method | Bag |
| Packaging Quantity | 1000 |
| Contact Base Material | Brass |
| Contact Size | 16 |
| Accepts Wire Insulation Diameter Range | 1.02 – 1.57 |
| Contact Mating Area Plating Material | Gold |
| For Use With | G Series Connectors |
| Connector & Contact Terminates To | Wire & Cable |
| Test Current (A) | 13 |
| Product Type | Contact |
| Color Code | Yellow/Red |
| TE Internal Number | 201580-1 |
| Contact Retention Type Within Housing | Crimp Snap-In |
| Termination Type | Crimp |
| Contact Type | Socket |
| Wire/Cable Type | Discrete Wire |
| Wire Size | 24 – 20 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 201580-1 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
3,820
|
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Chip One Stop |
28,854
|
|
Visit Site | |
| Electro Enterprises, Inc. |
1,900
|
|
Visit Site | |
| Heilind Electronics |
3,894
|
|
Visit Site | |
| Interstate Connecting Components |
909
|
|
Visit Site | |
| Newark |
8,045
|
|
Visit Site | |
| Onlinecomponents |
9,640
|
|
Visit Site | |
| Powell Electronics |
17
|
1 x $9.26
|
Visit Site | |
| Sager |
|
20,000 x $3.14
|
Visit Site | |
| TME |
28,854
|
|
Visit Site | |
| TTI Americas |
8,882
|
|
Visit Site | |
| Verical |
3,860
|
|
Visit Site |
No issues have been reported for the 201580-1
