211431-6
Contact SKT 22 Size Crimp ST Cable Mount Tray
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 211431-6 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 211431-6
| Part Name | 211431-6 |
| Manufacturer | TE Connectivity |
| Contact Mating Area Plating Thickness | 50 |
| Contact Size | 22 |
| Contact Base Material | Copper Alloy |
| Contact Length | 32.74 |
| Termination Post Length | .375 |
| Material | Copper Alloy |
| Packaging Method | Tray |
| TE Internal Number | 211431-6 |
| Contact Configuration | Front Release |
| Contact Type | Socket |
| Post Type | Round |
| Contact Mating Area Plating Material | Gold |
| For Use With | Mates with Pin |
| Contact Orientation | Straight |
| Product Type | Contact |
| Connector & Contact Terminates To | Wire & Cable |
| RoHS | True |
