2134439-2
Connector Accessories ILM Wide LGA Socket Stainless Steel
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2134439-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2134439-2
| Part Name | 2134439-2 |
| Manufacturer | TE Connectivity |
| Top Support Plate Material | Stainless Steel |
| Frame Style | Wide |
| Spring Plate Assembly Material | Stainless Steel |
| Operating Temperature Range | -25 to 100 |
| Accessory Type | ILM Assembly |
| Socket Type | LGA 2011 |
| Packaging Method | Bag/Box |
| TE Internal Number | 2134439-2 |
| Insulator Material | Polycarbonate Film Plus Acrylic Adhesive Layer |
| Product Type | Accessory |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 2134439-2 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
56
|
|
Visit Site | |
|
★ Featured
|
82
|
|
Visit Site | |
|
★ Featured
|
107
|
|
Visit Site | |
| Onlinecomponents |
839
|
|
Visit Site | |
| Verical |
268
|
|
Visit Site |
No issues have been reported for the 2134439-2
If you experienced any issues with this part, please report it.
