2273115-2
Cable Assembly M12 strgt plug to M12 strgt socket AA 8 POS
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2273115-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2273115-2
| Part Name | 2273115-2 |
| Manufacturer | TE Connectivity |
| Overall Outside Cable Diameter | .236 |
| Keying | A |
| Housing Material | Plastic |
| Cable Assembly Length | 600 |
| Operating Voltage (V) | 30 |
| Number of Positions | 8 |
| M8/M12 Application Type | Sensor/Actuator |
| Cable Jacket Color | Gray |
| Contact Current Rating (A) | 2 |
| Screw & Hole Thread Size | M12 x M12 |
| TE Internal Number | 2273115-2 |
| Configuration | Double Ended |
| Cable Assembly Type | M12 to M12 |
| Connector Color | Blue |
| Operating Temperature Range | -40 – 80 |
| Shielded | No |
| Packaging Method | Box |
| Connector Type | Plug/Receptacle |
| Packaging Quantity | 1/Carton |
| Wire Color | Brown, White, Blue, Black, Gray, Pink, Violet, Orange |
| RoHS | True |
| Mounting Angle | Straight-Straight |
| Product Type | Cable Assembly |
| Cable Type | PUR |
| Field Serviceable | Yes |
| Wire Size | 24 |
| Insulation Material | PUR |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
