2316670-3
Receptacle Contact HD1 REC CONTACT AU0.38 L SIZE
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2316670-3 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2316670-3
| Part Name | 2316670-3 |
| Manufacturer | TE Connectivity |
| Underplate Material Thickness | 50 |
| Contact Base Material | Copper Alloy |
| Circuit Application | Signal |
| Contact Classification | Signal |
| Contact Mating Area Plating Material | Gold |
| Wire/Cable Type | Discrete Wire |
| Operating Voltage (V) | 600 |
| Connector & Contact Terminates To | Wire & Cable |
| Contact Retention Type | Spring |
| Termination Method to Wire & Cable | Crimp |
| TE Internal Number | 2316670-3 |
| Connector System | Wire-to-Wire |
| Contact Retention | With |
| Contact Underplating Material | Nickel |
| Sealable | No |
| Operating Temperature Range | -55 – 105 |
| Contact Configuration | Crimp |
| Contact Termination Area Plating Material | Nickel |
| Accepts Wire Insulation Diameter Range | 1.08 – 1.9 |
| Barrel Type | Open Barrel |
| 端子の下地めっきの材料 | Nickel |
| Wire Range Mark | L |
| Contact Current Rating (Max) (A) | 3 |
| Contact Mating Area Plating Thickness | 15 |
| Contact Type | Receptacle |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Wire Size | 28 – 22 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 2316670-3 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
24,000 x $0.19
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Chip One Stop |
6,000
|
6,000 x $0.24
|
Visit Site | |
| Newark |
6,000
|
6,000 x $0.25
|
Visit Site | |
| Onlinecomponents |
6,000
|
|
Visit Site | |
| Sager |
|
24,000 x $0.25
|
Visit Site | |
| TME |
6,000
|
6,000 x $0.29
|
Visit Site |
