23K256-I/SN

Name: 23K256-I/SN
Brand: Microchip

Microchip 23K256-I/SN SRAM Memory, 256kbit, 2.7 - 3.6 V, 25ns 8-Pin SOIC | Microchip Technology Inc. 23K256-I/SN

Availability: Out of Stock

Package Type: SO-8

CAD Models: Symbol, Footprint, 3D Model

Check availability

Check availability

Add to Library See Datasheet PDF Pricing Pinout

What is SnapMagic Search?

SnapMagic Search is a free library of symbols & footprints for the 23K256-I/SN by Microchip and for millions of electronic components.

Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.

Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.

Symbol and Footprint
3D Model
Alternates

Symbol

No web preview

This Symbol is Available for

This symbol was not created by SnapMagic Search, please be cautious when using it in your design

Downloaded times

Footprint

No web preview

This Footprint is Available for

This footprint was not created by SnapMagic Search, please be cautious when using it in your design

Downloaded times

3D Model

Preview not available

Note: If you're using IE or Edge, right-click and choose "Save as" to download.

Relevant part with 2D models

Download Part

Verification

Issues

Specs

Pricing

No issues have been reported for the 23K256-I/SN

If you experienced any issues with the symbol or footprint, please report it.

New Issue

Specifications for the 23K256-I/SN

Part Name	23K256-I/SN
Manufacturer	Microchip
Category	Electronic Components
RoHS	True
Formats Available for Symbols and Footprints	Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus
Datasheet	See Datasheet PDF
Number Of Words	32 (k)
Low Power	Yes
Dimensions	4.9 x 3.9 x 1.25 (mm)
Maximum Operating Supply Voltage (V)	3.6 V
Timing Type	Synchronous
Organisation	32768 x 8 bit
Minimum Operating Temperature	-40 °C
Minimum Operating Supply Voltage (V)	2.7 V
Number Of Bits Per Word	8 (bit)
Automotive Standard	AEC-Q100
Memory Size	256 (kbit)
Width	3.9 (mm)
Length	4.9 (mm)
Clock Frequency	20 (MHz)
Package Type	SOIC
Address Bus Width	16 (bit)
Maximum Random Access Time	25 (ns)
Mounting Type	Surface Mount
Height	1.25 (mm)
Maximum Operating Temperature	+85 °C
Pin Count	8
