2904636
Cable Assembly;halogen-free cable;2x50 position;FLK 50-PA/EZ-DR/HF/KS/ 500/YUC | Phoenix Contact 2904636
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 2904636 by Phoenix Contact and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 2904636
| Part Name | 2904636 |
| Manufacturer | Phoenix Contact |
| Category | Wire & Cable |
| Product Article Number Of Manufacturer | 2904636 |
| Product Description | Front adapter |
| Type Of Electrical Accessories | Adapter |
| Net Weight | 1.08 |
| Mounting Design | field device attachment |
| Height | 202.75786 |
| Width | 92.7 |
| Depth | 159.44143 |
| Type Of Enveloping Body | enveloping body cuboid |
| GTIN | 4046356868389 |
| Gtin (ean) Code | 4046356868389 |
| Manufacturer Product Designation | Front adapter |
| Internal Article Number | 2904636 |
| Number Of The Executions Of The Housing Parts | 0 |
| RoHS | True |
| Life Cycle Status | End of Life |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
No issues have been reported for the 2904636
If you experienced any issues with this part, please report it.
