3-5147490-2
Socket Receptacle Connector Next Gen PACE Conn 32 POS 1X2 64 POS
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 3-5147490-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 3-5147490-2
| Part Name | 3-5147490-2 |
| Manufacturer | TE Connectivity |
| Zeilenanzahl | 2 |
| Centerline (Pitch) | 2.54 |
| Circuit Application | Signal |
| Termination Method to Printed Circuit Board | Through Hole - Press-Fit |
| Connector & Contact Terminates To | Printed Circuit Board |
| Connector Style | Receptacle |
| Contact Mating Area Plating Material Thickness | .76 |
| Number of Positions | 64 |
| PCB Mount Retention Type | Action/Compliant Tail |
| PCB Mount Retention | With |
| Connector System | Board-to-Board |
| Termination Post & Tail Length | 3.18 |
| TE Internal Number | 3-5147490-2 |
| PCB Mount Orientation | Vertical |
| PCB Mount Alignment | Without |
| Housing Color | Black |
| Contact Underplating Material | Nickel |
| Number of Dual Positions | 32 |
| Contact Base Material | Phosphor Bronze |
| Connector Mounting Type | Board Mount |
| PCB Contact Termination Area Plating Material Thickness | 100 |
| Mating Retention | Without |
| Operating Temperature Range | -67 – 185 |
| Packaging Method | Package |
| Card Slot Depth | .42 |
| Packaging Quantity | 108 |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Housing Material | Polyester - GF |
| 端子の下地めっきの材料 | Nickel |
| Height | .55 |
| Row-to-Row Spacing | .2 |
| Contact Current Rating (Max) (A) | 3 |
| Contact Retention | Without |
| Connector Contact Load Condition | Fully Loaded |
| PCB Contact Termination Area Plating Material Finish | Matte |
| Contact Type | Socket |
| PCB Contact Termination Area Plating Material | Tin |
| Board-to-Board Configuration | Mezzanine |
| Mating Alignment | With |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
