345263-1
070 SERIES TAB
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 345263-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 345263-1
| Part Name | 345263-1 |
| Manufacturer | TE Connectivity |
| Sealable | No |
| Wire Type | Copper |
| Operating Temperature Range | -30 – 105 |
| Terminal & Splice Type | Tab |
| Packaging Method | Reel |
| Wire Insulation Diameter | .094 – .106 |
| TE Internal Number | 345263-1 |
| Packaging Quantity | 4000 |
| Crimp Type | F-Crimp |
| Interface Plating | Tin (Sn) |
| Typical Current Rating (A) | 14 |
| Wire Size Search | 14 |
| Termination Method | Crimp |
| Terminal Transmits | 0 – 24 A (Low Power) |
| Wire Size | 2 |
| RoHS | True |
| Mating Tab Width | 1.8 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
