3FTH9
Tactile Switch SPST-NO Side Actuated Through Hole, Right Angle
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 3FTH9 by MEC Switches and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 3FTH9
| Part Name | 3FTH9 |
| Manufacturer | MEC Switches |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Actuator Type | Cap |
| Operating Force | 3.5 N |
| Actuator Colour | Black |
| Dimensions | 10.10 x 10.10 x 10.4 (mm) |
| Mounting Type | Through Hole |
| Ip Rating | IP67 |
| Contact Current Rating (A) | 50 mA |
| Terminal Type | Pc Pin |
| Voltage Rating (V) | 24 (V dc) |
| Contact Configuration | SPST |
| Width | 10 (mm) |
| Length | 10 (mm) |
| Minimum Operating Temperature | -40 (°C) |
| Actuator Length | 4 (mm) |
| Operating Temperature Range | -40 → +160 (°C) |
| Height | 10.4 (mm) |
| Maximum Operating Temperature | +160 (°C) |
| Mechanical Life | 10000000 (Operations) |
| Switch Operation | Momentary |
