4-87962-8
SnapVerified
98 MODII HORZ DR CE 100CL/115
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 4-87962-8 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 4-87962-8
| Part Name | 4-87962-8 |
| Manufacturer | TE Connectivity |
| Centerline (Pitch) | 2.54 |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Connector & Contact Terminates To | Printed Circuit Board |
| Number of Positions | 98 |
| PCB Mount Retention | Without |
| PCB Thickness (Recommended) | .062 |
| Termination Post & Tail Length | 2.92 |
| TE Internal Number | 4-87962-8 |
| PCB Mount Orientation | Right Angle |
| Contact Protection Type | Closed Entry Housing |
| Connector Height | 6.05 |
| Number of Rows | 2 |
| PCB Contact Termination Area Plating Material Thickness | 50 |
| Sealable | No |
| Housing Color | Natural |
| Mating Entry Location | Side |
| High Temperature Compatible | No |
| Packaging Method | Tube |
| Packaging Quantity | 20 |
| Contact Configuration | Short Point |
| Contact Type | Socket |
| Contact Mating Area Plating Material | Gold |
| Stackable | No |
| RoHS | True |
| Housing Material | Polyphenylene Sulfide (PPS) |
| Contact Base Material | Phosphor Bronze |
| Contact Mating Area Plating Material Thickness | 50 |
| Row-to-Row Spacing | .1 |
| PCB Connector Assembly Type | PCB Mount Receptacle |
| Connector Profile | Standard |
| Solder Process Feature | Board Standoff |
| PCB Contact Termination Area Plating Material | Gold |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 4-87962-8 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
40 x $387.08
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Conrad |
15
|
1 x $271.41
|
Visit Site | |
| Heilind Americas |
|
40 x $335.13
|
Visit Site | |
| Interstate Connecting Components |
|
40 x $335.13
|
Visit Site | |
| Newark |
15
|
1 x $374.38
|
Visit Site | |
| Onlinecomponents |
3
|
|
Visit Site | |
| Powell Electronics |
10
|
|
Visit Site | |
| Sager |
|
20 x $418.92
|
Visit Site |
No issues have been reported for the 4-87962-8
